Product Description
this PMK-FB serial press die is a Square assemble die which made by high-speed tool steel from Alloy Tool Steel Cr12MoV, it's indenter hardness is HRC60-HRC62. The Square assemble die has several sample size for choose:12*12mm;15*15mm;18*18mm;20*20mm.The cavity depth is 40mm.
Technical Parameter
Model No. | PMK-FB |
Die Material | Alloy Tool Steel:Cr12MoV |
Indenter Hardness | HRC60-HRC62 |
Sample Size | 12*12mm;15*15mm;18*18mm;20*20mm |
Cavity Depth | 40mm |
Dimension | Φ73*133mm |
Weight | 3.6Kg |
